SS-UCFCPL
KZ SERIES: SS-UCFCPL204 -UCFCPL208 SS-UCFCPL212
Category Thermoplastic Bearing
MATERIAL : Housing unit: PBT glass-filled thermoplastic polyamide
INSERT BEARING : Stainless Steel 420.
SS-UCFCPL: With a circular 4-bolt flange housing, the SS-UCFCPL provides centralized, balanced support for rotating shafts. Made from high-strength thermoplastic and stainless steel, it ensures excellent corrosion resistance in wet, chemical, or sanitary applications. The round shape distributes loads evenly, reducing vibration and misalignment. Ideal for mixers, agitators, and vertical mountings in food and pharmaceutical settings, it combines secure mounting with low-maintenance operation.
Applications and industry: Automotive, Food and beverage processing, Packaging, Textile and printing.
| Bearing Number | Inner Diameter (d) MM | Outer Diameter (D) MM | Width (B) MM | Basic Load Rating (N) Dyn. C | Basic Load Rating (N) Stat. C0 | LIMITTING SPEED ( R/MIN ) LUBRICATION Grease | LIMITTING SPEED ( R/MIN ) LUBRICATION Oil | Weight (KG) |
|---|---|---|---|---|---|---|---|---|
| SS-UCFCPL204 | 20 3/4 | 31.0 1.220 | 0.59 | |||||
| SS-UCFCPL205 | 25 13/16; 718; 15/16;1 | 34.1 1.343 | 0.71 | |||||
| SS-UCFCPL206 | 30 1-1/16 ;1-1/8 ; 1-3/16; 1-1/4 | 38.1 1.500 | 0.94 | |||||
| SS-UCFCPL207 | 35 1-1/4 ;1-5/16 ; 1-3/8; 1-7/16 | 42.9 1.689 | 1.17 | |||||
| SS-UCFCPL208 | 40 1-1/2; 1-9/16 | 49.2 1.937 | 1.42 | |||||
| SS-UCFCPL209 | 45 1-5/8;1-11/16 ; 1-3/4 | 49.2 1.937 | 1.55 | |||||
| SS-UCFCPL210 | 50 1-13/ 16;1-718; 1-15/16;2 | 51.6 2.031 | 1.76 | |||||
| SS-UCFCPL211 | 55 2; 2-1/16 ; 2-1/8; 2-3/16 | 55.6 2.189 | 2.15 | |||||
| SS-UCFCPL212 | 60 2-1/4 ; 2-5/16 ; 2-3/8 ;2-7/16 | 65.1 2.563 | 2.64 |
.jpeg)
