SNU 500
KZ SERIES :SNU 505, SNU 506-605, SNU 509, SNU 517
Plummer blocks supports have as their main advantage in their simple installation. In them, it is possible to install preassembled shafts.
Bearing support is an element that can function as a support, as a flange, or as a tensioner of the bearing.
Bearings facilitate the movement between a shaft and the parts attached to it. There are a lot of types depending on different aspects such as loads, accuracy, rolling elements, or speed.
Applications and industry: AGRICULTURE, AUTOMOTIVE, CEMENT INDUSTRY, CRUSHER INDUSTRY, HEAVY MACHINERY EQUIPMENTS, HOME APPLIANCES, MINING SECTOR, METAL INDUSTRY, FLUID MACHINERY, TEXTILE INDUSTRY
| Bearing Number | Inner Diameter (d) MM | Width (B) MM | d1 | Inch | Ball Diameter (MM) | Thread G | w | i | C1 (MM) | d3 | H1 | d2 | r1 Min | Dynamic Load Capacity | Static Load Capacity | Weight (KG) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SNU505 | 20 | 19 | 1.5 | |||||||||||||
| SNU506-605 | 25 | 22 | 2 | |||||||||||||
| SNU507-606 | 30 | 22 | 2.2 | |||||||||||||
| SNU508-607 | 35 | 25 | 2.8 | |||||||||||||
| SNU509 | 40 | 25 | 3 | |||||||||||||
| SNU510-608 | 45 | 25 | 3.1 | |||||||||||||
| SNU511-609 | 50 | 28 | 4.5 | |||||||||||||
| SNU512-610 | 55 | 30 | 5 | |||||||||||||
| SNU513-611 | 60 | 30 | 6.1 | |||||||||||||
| SNU515-612 | 65 | 30 | 6.5 | |||||||||||||
| SNU516-613 | 70 | 32 | 9 | |||||||||||||
| SNU517 | 75 | 32 | 10.2 | |||||||||||||
| SNU518-615 | 80 | 35 | 12.4 | |||||||||||||
| SNU519-616 | 85 | 35 | 13.5 | |||||||||||||
| SNU520-617 | 90 | 40 | 17.5 | |||||||||||||
| SNU522-619 | 100 | 45 | 20.5 | |||||||||||||
| SNU524-620 | 110 | 45 | 25.5 | |||||||||||||
| SNU526 | 115 | 50 | 33 | |||||||||||||
| SNU528 | 125 | 50 | 42 | |||||||||||||
| SNU530 | 135 | 60 | 53 | |||||||||||||
| SNU532 | 140 | 60 | 55 |
