UCT 200 UCT305

Technical Details

Bore Diameter (mm) d	Outer Diameter (mm) D	Width (mm) B	Weight (Kg)
25	16	38	1.2

KZ SERIES : UCT 201

These are Wide Metric Slot Take-up Housing Units with taking up for threaded rod and nut, guided groove on both sides, and are relubricated. We are a widely recognized supplier and trader of a huge gamut of taking Up Unit Bearings (UCT) in India. These are sourced from the house of reliable vendors and manufactured with ultra-modern techniques. Superior performance at a cheaper market price. The UCT Take Up Unit has narrow machined grooves on either side to allow movement on suitably machined rails, and a tapped hole in the base to attach a threaded bar to facilitate the adjustment. They are typically used for conveyor roller tension systems.

Available in metric and inch sizes.

Applications and industry: AGRICULTURE, AUTOMOTIVE, CEMENT INDUSTRY, CRUSHER INDUSTRY, HEAVY MACHINERY EQUIPMENTS, HOME APPLIANCES, MINING SECTOR, METAL INDUSTRY, FLUID MACHINERY, TEXTILE INDUSTRY

Send query Buy Now

UCT 300 UCT305

Technical Details

Bore Diameter (mm) d	Outer Diameter (mm) D	Width (mm) B	Weight (Kg)
25	16	65	1.2

KZ SERIES : UCT 305

UCT305 Available in metric and inch sizes.

KZ BEARING SERIES: UCT 200, UCT 300

Send query Buy Now

Bearing Number	Inner Diameter (d) MM	Outer Diameter (D) MM	g	Weight (KG)
UCT305	25	16	14	1.2
UCT305-13	13/16	5/8	9/16	1.2
UCT305-14	7/8	5/8	9/16	1.2
UCT305-15	15/16	5/8	9/16	1.2
UCT305-16	1	5/8	9/16	1.2
UCT306	30	18	16	1.7
UCT306-17	1-1/16	23/32	5/8	1.7
UCT306-18	1-1/8	23/32	5/8	1.7
UCT306-19	1-3/16	23/32	5/8	1.7
UCT307	35	20	17	2.3
UCT307-20	1-1/4	12/32	43/64	2.3
UCT307-21	1-5/16	12/32	43/64	2.3
UCT307-22	1-3/8	12/32	43/64	2.3
UCT307-23	1-7/16	12/32	43/64	2.3
UCT308	40	22	19	2.9
UCT308-24	1-1/2	7/8	3/4	2.9
UCT308-25	1-9/16	7/8	3/4	2.9
UCT309	45	24	20	4
UCT309-26	1-5/8	15/16	25/32	4
UCT309-27	1-11/16	15/16	25/32	4
UCT309-28	1-3/4	15/16	25/32	4
UCT310	50	27	22	5
UCT310-29	1-13/16	1-1/16	7/8	5
UCT310-30	1-7/8	1-1/16	7/8	5
UCT310-31	1-15/16	1-1/16	7/8	5
UCT311	55	29	23	6.2
UCT311-32	2	1-5/32	29/32	6.2
UCT311-33	2-1/16	1-5/32	29/32	6.2
UCT311-34	2-1/8	1-5/32	29/32	6.2
UCT311-35	2-3/16	1-5/32	29/32	6.2
UCT312	60	31	25	7.5
UCT312-36	2-1/4	1-7/32	31/32	7.5
UCT312-37	2-5/16	1-7/32	31/32	7.5
UCT312-38	2-3/8	1-7/32	31/32	7.5
UCT312-39	2-7/16	1-7/32	31/32	7.5
UCT313	65	32	27	9.3
UCT313-40	2-1/2	1-17/64	1-1/16	9.3
UCT313-41	2-9/16	1-17/64	1-1/16	9.3
UCT314	70	36	27	10.9
UCT314-42	2-5/8	1-13/32	1-1/16	10.9
UCT314-43	2-11/16	1-13/32	1-1/16	10.9
UCT314-44	2-3/4	1-13/32	1-1/16	10.9
UCT315	75	36	27	12.7
UCT315-45	2-13/16	1-13/32	1-1/16	12.7
UCT315-46	2-7/8	1-13/32	1-1/16	12.7
UCT315-47	2-15/16	1-13/32	1-1/16	12.7
UCT315-48	3	1-13/32	1-1/16	12.7
UCT316	80	42	30	15.8
UCT316-49	3-1/16	1-21/32	1-3/16	15.8
UCT316-50	3-1/8	1-21/32	1-3/16	15.8
UCT316-51	3-3/16	1-21/32	1-3/16	15.8
UCT317	85	42	32	18.6
UCT317-52	3-1/4	1-21/32	1-1/4	18.6
UCT317-53	3-5/16	1-21/32	1-1/4	18.6
UCT317-55	3-7/16	1-21/32	1-1/4	18.6
UCT317-60	3-3/4	1-13/16	1-5/16	24.6
UCT318	90	46	32	21
UCT318-55	3-7/16	1-13/16	1-1/4	21
UCT318-56	3-1/2	1-13/16	1-1/4	21
UCT319	95	46	33	24.6
UCT319-58	3-5/8	1-13/16	1-5/16	24.6
UCT319-59	3-11/16	1-13/16	1-5/16	24.6
UCT320	100	48	32	29.9
UCT320-64	4	1-7/8	1-1/4	29.9
UCT322	110	52	38	39.4
UCT324	120	60	42	54.2
UCT326	130	65	45	68.4
UCT328	140	70	50	82.9
